MC one hole strap F

A standard way to secure cable pipes easily

Product image of the MC one hole strap F made from metal.
Product overview

The MC one-hole strap F has a double reinforced rib that extends up to the angle of the clip which offers greater strength and resistance to bending. It is made from metal and has a zinc-plated coating that helps protect it from corrosion.

Show more
List of references
Reference
d
J
912F
Material
d
J
Steel
Width (in)
d
J
0.472
Lengh (inches)
d
J
1.094
Height (inches)
d
J
0.527
Sheet thickness (inches)
d
J
0.031
Diameter (in)
d
J
0.472
Suitable for (inches)
d
J
Pipe Ø 0,3937-0,5511
Packaging units
d
J
100
Packaging type
d
J
Box
A
t
1 / 1 references
Applications
  • PVC pipes
  • Multilayer pipes
  • Steel pipes
  • Copper pipes
  • Cable fixing
Further specifications

Key features:

  • Can be fixed with nail plug, concrete screw BTS-5 or direct metal anchor DA
  • Recommended loads up to 12 Kg including safety factor
  • Double rib offers greater resistance to bending
  • Hole Ø6.5 mm for through out fixing installations

Base materials:

  • Concrete
  • Solid brick
  • Solid sand-lime brick
  • Natural stone
